Product Description

highly performance original korea g-scan 2 with System and DTC Auto Search coverage for Asian cars and Trucks wholesale price


In-depth coverage for Asian cars and Trucks
Vehicle communication part is designed fully compatible with G-scan, which enables the continued provision of unchallenged in-depth diagnostic capability on Asian passenger cars and commercial vehicles.


System and DTC Auto Search
“System Search’ option checks all the systems fitted in the car automatically and reports the number of fault codes found and availability of advanced diagnostic functions in each detected system

Screen Capture and Memo
Simply capture the screen any time and add quick hand written notes on the screen. It can be saved and reloaded for future reference.

Favorite and Recent
Bookmark the frequently used functions in the “Favorite” menu, and call the function as needed without having to navigate all the menu layers each time.
The “recent” menu serves as the shortcut to the functions that need to execute in short repetition.

Full Text Description
High resolution LCD screen and the 2-line DTC description display feature enables G-scan2 to show the long-text DTC descriptions in full preventing the use of the acronyms or cutting away the significant parts to fit in the limited text space.

Smart Update
Smart Update system provides more flexibility for software management. The old and new versions for each marque can be downloaded from GIT’s server directly as per personal preferences.

CAN Line Inspection
G-scan2 offers the function that detects the signal transmission of the CAN-Bus lines, and indicates the status of CAN-Bus signals by showing the illuminating lamp symbols on the screen to help instantly identify the hardware defect of CAN-Bus system.

Simple and easy menu structure
If International is selected, a simple Diagnostic Connector Type selection follows and then the system selection can be made without having to follow further model name, model code, type or model year selections. It is so simple but it is not providing a simplified function. It provides complete function and diagnostic result of the same level as selecting all the details of the test car in Japan Domestic.

Utility Functions
G-scan2 offers a variety of utility functions like Communication Line Inspection, Unit Converter, Calculator, Special Functions Calculator
(Ohm’s Law, Parallel Resistance, Frequency and Period, Tire Distance per rotation, Percentage) for user’s convenience.

Dual Mode for Hyundai and Kia
Hyundai and Kia software of G-scan2 supports dual mode where the 2 of the diagnostic functions
(DTC Analysis, Data Analysis, Actuator Test and Simulator) are executed and displayed simultaneously.

Flight Record
Data Parameters can be recorded any time during the test as the Flight Record which can be replayed in numeric or graphical form.

Basic SuppliesParts included in the Basic and Trade-in Kit
Part  Part Number  Description  Q’ty
   G1FDDMN029(Blue)
G1FDDMN020(Black) Part Name: G-scan2 Base Unit
G-scan2 base unit with battery pack and SD Card
(VMI module replaces battery pack for VMI Pack options)  1
   A2MDT2SD16G Part Name: SD Card 16GB
Provided included in the base unit.
A memory card that contains software and data for diagnostic functions.  1
   G1FZFCA001 Part Name: Cable – DLC Main Cable
The main cabled used for connecting the G-scan2 base unit and the car’s OBD2 connector.  1
   A2MDK1CCRP5 Part Name: SD Card Reader
A USB card reader used for connecting the SD Card to the PC.
(Specs can be changed without notice)  1
   G1CDDPA008 Part Name: Self Test Adapter
A cable used for self test of G-scan2 base unit and the cable connection.
Do not use this cable for vehicle diagnostic functions  1
   G1PZGDP001 Part Name: PC Utility CD (S/W)
A CD that contains the G-scan2 PC utility installation program and soft copy of user’s guide.  1
   G1FZDHA001 Part Name: Carrying Hard Case
A portable and heavy duty
hard case that contains
G-scan2 base unit and parts.  1
   G1CDDPA013 Part Name: AC/DC Adapter
AC to DC converter used for supply of AC power to the G-scan2 base unit.  1
   G1CDECA001 (Europe, Korea) G0PDDCN001(Australia)
G0PDDCN002(UK, Malaysia)
G1PDDCA002(North America) Part Name: AC Power Cord
AC power cord used with the AC/DC adapter for supply of AC power to G-scan2 base unit Different type AC plugs may apply for different countries i.e. Korea, USA. Australia and UK. Spec: IEC 60320 C13  1
   G2SDDCA003 Part Name: Cable – Battery
A power supply cable used together with the Cigarette Lighter Cable when supplying power from the car’s battery.  1
   G1PDDCA002 Part Name: Cable-Cigarette Lighter
A power supply cable used when supplying power from the car’s cigarette lighter socket.  1
   G1FZTZM001 Quick Manual
A single piece laminated paper manual for quick guidance for G-scan2 usage.
