Product Description

Brand programmer
 ■ Support 48 Pin universal drive, free software update download
■Three-year quality assurance, no worries ■ Small size, powerful function, easy to carry
■Pin foot automatic detection, providing real-time detection information ■Support for In-circuit programming (ISP)
■Multi-machine mass production via USB Hub ■Provide detailed real-time help documentation and related IC data
■ TTL/CMOS logic IC and Memories PREFIX = O

Can support 75000+IC



summary

◆ ELNEC's new USB-compatible universal burner based on the Windows 95/98/ME/NT/2000/XP/win7 interface is a good member of the growing society for fast and reliable universal programmers.

◆ Silicon technology capable of supporting various types, current and future programmable devices without a series of specific MODULE. The method can freely select for design. By using the ISP connector, the programmer can Programming supports ISP chips.

◆ BeeProg2C is not only a programmer but also TTL/COMS logic IC and memory. Also, it allows users to use a range of test methods.

◆ Provide very competitive price, for regular programming plus excellent hardware design, in this respect is a good price/performance programmer.
Because of the high-speed FPGA hardware driver and the programmer's internal timing program run, it has breakneck programming speed. From this point of view, it is at least faster than competing products. For many chips, the programming speed is faster than that of competing products. When you want to produce on the burner, wait for the operation, unlike other complete activities.

◆BeeProg2C can connect to IBM 486 or above PC, portable, personal desktop computer through USB (2.0/1.1) port or any standard parallel (printer) port. The programmer also supports IEEE1284 (ECP/EPP) high-speed parallel port. Supports selected USB/LPT ports for BeeProg+ to any PC, from the nearest laptop to an older desktop without a USB port

.

hardware

◆ FPGA based on 48 powerful TTL pin drivers, providing High/Low/Pullup/Pulldown/read function for each pin on the test socket. Advanced drive technology combines the reliability of high-speed and high-quality lines. Supports low voltage 1.8v, so you can use it to program the currently popular low voltage devices.

◆ The programmer provides insertion test and contact test before the program and can prevent chip damage caused by improper placement. These performances prevent chip damage due to over-current protection and flow check due to misoperation.

◆ Embedded protection circuit can eliminate the damage of the programmer or damage the programmer due to environmental or misoperation. All inputs of the BeeProg2C programmer, including the ZIF test socket, the advanced drive technology connected to the PC provides high speed, high quality, and reliability. Performance. Support voltages as low as 1.8v, so you can use it to program all current popular low voltage devices.

◆ The programmer provides contact testing before programming and can prevent chip damage caused by improper placement. These prevent damage to the chip due to misoperation through overcurrent protection and flow detection.

◆ Embedded protection circuit can eliminate the damage of the programmer or due to environmental or misoperation. All inputs of BeeProg2C programmer, including ZIF test socket, connected PC, and power supply, are protected to prevent ECD from rising to 15KV. BeeProg2C programmer Perform edge-level voltage burn-in verification, which provides programming areas and maintains extensive data.

◆ A variety of adapters support a variety of IC packages, such as PLCC, SOIC, PSOP, SSOP, SSOP, TSOPTSSLP, TQFP, QFN (MLF) SDIP, BGA, etc.

Software

◆ This programmer is easy to use and control, with drop-down menus, shortcut keys, and online help. Select devices can select by various methods such as classification, manufacturer, model, serial number and so on.

◆ related standard programming operation commands (read, blank check, program, verify, erase), and some test functions (insert test, flow detection), also include some additional features such as (autoincrement, product mode - after entering the chip Start burning immediately.)

◆ Support all known data formats, automatically recognize and convert the appropriate file format when importing files.

◆Auto-increment programming function can assign different serial numbers in each IC, or increment the serial number, or choose to read the serial number from the user's file. The programmer software provides detailed IC information including painting. A variety of useful packages, descriptions of chip tags (prefix and suffix meaning).

◆ The programmer software provides detailed ISP information, including ISP interface definition for the currently selected IC, IC peripheral circuit design, and other necessary information. Other application commands use BAT or DLL files, and remote control allows PG4UW software flow control. Jam Player describes the JAR file in the JEDEC standard JESD-71, and the Jam file generated by the design software provided by the manufacturer of the respective programmer. The chip programming in the ZIF socket or the ISP connector (IEEE1149.1 JTAG interface).

VME Player describes VME files. VME files are a binary variant of SVF file compression, including high-level IEEE 1149.1 bus implementation. VME files generated by the design software provided by the respective programmers. The chip is in the ZIF socket or ISP connector ( IEEE1149.1 JTAG interface) programming. It is possible to program and detect multiple devices via JTAG chain (ISP-Jam or ISP-VME).

◆ A powerful multi-programming program can connect multiple BeeProg2C programmers on the same PC (via USB port), support many chips, as supported by a single BeeProg2C programmer, and it will not significantly reduce the programming speed. As we all know, collaborative multi-programming - each programmer can work independently; each programmer can also program different chips.
